Oil Mist Filter Filters Oil Mist
The operation of a vacuum pump will result in the emission of oil mist, which can have a negative impact on the environment. Many countries also have strict restrictions on industrial pollution and oil fume emissions. The oil mist filter can help you solve this problem. The principle of the oil mist filter is simple yet effective: through physical filtration and coalescing techniques, it traps and removes oil mist.
Firstly, physical filtration. The oil mist pass through the filter medium inside, and the filter medium will capture and retain small oil droplets. The specification of filter should be carefully chosen to ensure efficient capture of oil mist particles without impeding the flow of air.
In the next stage, coalescing techniques are applied to further enhance the efficiency of the oil mist filter. The captured oil droplets are coalesced or joined together, forming larger oil droplets that are easier to trap and remove. This process is accomplished by allowing the smaller droplets to come into contact with coalescing media where they amalgamate. This results in the separation of the coalesced oil droplets from the air, which then drains into a collection container for later disposal or recycling.
By effectively removing oil mist from the vacuum system, the oil mist filter helps maintain a clean and efficient working environment. It also prevents oil contamination in downstream processes or vacuum chambers, protecting sensitive equipment, such as valves and gauges, from damage.
It's worth noting that replacement of the filter elements at recommended intervals is necessary to avoid clogging and maintain the efficiency of the oil mist filter. A properly functioning oil mist filter not only extends the lifespan of the vacuum pump but also reduces the need for costly repairs or replacements.
Post time: Oct-11-2023
